CSC Cleanroom Light Lineup
Choose the right tools in the right situation!
We, CSC, have several kinds of cleanroom light that have different strong
points. Using the right tools in the right situation is the best way to
solve the problem!
NP-1 |
Mini N |
L3SQ |
・For large workpieces (car parts, LCD, film, etc.)
・Check dusts after cleaning.
・Check dusts and flaws on work. |
・For small workspieces or inside the machine.
・Easy to carry around. |
・Bar type light
・For flat workpieces (LCD, glass, film, sheet, etc.)
・For setting in the inspection process. |


|
| Product Name |
Cleanroom Light NP-1 |
Cleanroom Light MINI N |
Dust Finder L3SQ |
| Model |
NP-1 |
CSPV-1000-N |
Light: CSDBA-LP200W-L2000-C02
AC Controller: CS-15AC |
| Power |
35W |
- |
115W (MAX) |
| Light Source |
HID |
LED |
LED |
| lx |
3400 lm |
1000 lm (MAX) |
- |
| Power Source |
Battery type,
AC Adaptor type
|
Batteries and dry cell batteries |
AC Adaptor type |
| Continuous time |
Battery type: ca. 90 mins,
AC Adaptor type: 24hr (with taking some break) |
High：5 hrs.
Mid:18 hrs.
Eco：35 hrs.
|
24 hrs.
(Please take some rests periodically) |
| Charge time |
ca. 3.5 hrs. |
6.5 hrs. |
- |
| Battery life |
400 - 500 cycles |
300 cycles |
- |
| Lamp life |
ca. 3,000 hrs. |
|
ca. 30,000 hrs. |
| Size |
95mm x 295mm x 135mm |
φ43×178（mm） |
Light part: 223m x 30mm x 31 mm
Switch part (Controller): 48 mm x 74mm x 30mm
AC adaptor, Cable length: 2500mm (From edge of light to adaptor) |
| Weight |
ca. 2.3 kg (Including battery) |
ca. 290 g (Including battery) |
Light part: ca. 270 g
Switch part: ca. 190 g |
| Fixing Method |
Fixable by tripod
(Please prepare tripod by yourself) |
- |
Stand tool (Option) |
| Spector |
 |
 |
 |
| Detail |
 |
 |
 |
